Liner Plate for Coal Mill

Mill Liner Plate Thickness is:

10mm, 12mm, 14mm, 15mm, 16mm, 18mm, 20mm, 15mm, 30mm, 32mm, 40mm, 50mm, 60mm, 80mm, 100mm, 200mm, 500mm, 1000mm.
Section Thickness is:
1 inch, 2 inch, 3 inch, 4 inch, 5 inch, 8 inch, 10 inch, 20 inch, 30 inch, 40 inch.
Material Grade is:
Cr-Mo Alloy Steel (ZG50Cr5Mo, ZG60Cr6Mo, Cr12Mo)
High Cr white iron (BTMCr15Mo, BTMCr20Mo, BTMCr26Mo)
We can fabricate the Ni-hard wear plates and Mill Liner Plates as per your material and your sizes.
We’d like to help select suitable material grade for your Mill Liner Plate as per your specific working condition.
Our can provide you with a complete set of Liner Plate bolts, washers, and nuts.
Ni-hard 1: ≥ HB500 G-X 330 NiCr 4 2 0.9625
Cast Iron Ni-hard 2: ≥ HB550 G-X 3260 NiCr 4 2 0.9620
White Iron Ni-hard 4: ≥ HB600, HB630 G-X 300 NiCrSi 9 5 2 0.9630
Martensitic Cr- Mo Alloy Steel Hardness is ≥HRC484.
Pearlitic Cr-Mo Alloy Steel Hardness is HB310-375
Our Photos for Liner Plate for Coal Mill:

  • Liner Plate
  • Liner Plate
  • Liner Plate
Mill Liner Plate Material Grades:

Reference Standard Nominal Chemical Composition (W%) Eqv. Standards
ISO 21988-2005 C Si Mn P S Ni Cr
HBW480Cr2 2.5-3.0 ≤0.8 ≤0.8 ≤0.10 ≤0.10 3.0-5.5 1.5-3.0 BTM Ni4Cr2-DT, EN-GJN-HV520, AS2027 NiCr2-500, ASTM A532 Ni-Cr-Lc, G-X 260 NiCr 4 2
HBW500Cr9 2.4-2.8 1.5-2.2 0.2-0.8 ≤0.06 ≤0.06 4.0-5.5 8.0-10.0 EN-GJN-HV550 Ni-Cr-Hc, AS2027 NiCr1-550, G-X 330 NiCr 4 2
HBW510Cr2 3.0-3.6 ≤0.8 ≤0.8 ≤0.10 ≤0.10 3.0-5.5 1.5-3.0 BTM Ni4Cr2-GT,AS2027 NiCr4-500,ASTM A532 C1-B Ni-Cr-Hc,ASTM A532 C1-C Ni-Cr-GB
HBW555Cr9 2.5-3.5 1.5-2.5 0.3-0.8 ≤0.08 ≤0.08 4.5-6.5 8.0-10.0 BTM Cr9Ni5, EN-GJN-HV600, AS2027 NiCr4-600, G-X 300 CrNiSi9 5 2
HBW630Cr9 3.2-3.6 1.5-2.2 0.2-0.8 ≤0.06 ≤0.06 4.0-5.5 8.0-10.0 BTM Cr9Ni5,AS2027 NiCr4-630,ASTM A532 C1-D Ni-HiCr
Specification:
According to drawings, heat resistance, surface treatment requirement, Various types of 2D or 3D drawings are acceptable, etc.
Cost effective:
Integrated production from mold-making to post-processing is completed in our own factory.
This can effectively reduce the manufacturing cost.
We have first rate production line, the most professional staff, and the advanced equipment and inspection method for casting.
super quality,competitive price and strict delivery time.

Reference Standard Nominal Chemical Composition (W%)
C Si Mn Cr Mo Ni P S
AS 2017/L2A 0.45-0.55 ≤0.75 0.50-1.00 0.80-1.20 - - ≤0.04 ≤0.04
AS 2017/L2B 0.55-0.65 ≤0.75 0.50-1.00 0.80-1.50 0.2-0.4 - ≤0.04 ≤0.04
AS 2017/L2C 0.70-0.90 ≤0.75 0.50-1.20 1.30-2.40 0.2-0.4 - ≤0.04 ≤0.04
ZG42Cr2Si2MnMo 0.38-0.48 1.5-1.8 0.8-1.2 1.8-2.2 0.2-0.6 - ≤0.04 ≤0.04
ZG45Cr2Mo 0.40-0.48 0.8-1.2 0.4-1.0 1.7-2.0 0.8-1.2 ≤0.5 ≤0.04 ≤0.04
ZG30Cr5Mo 0.25-0.35 0.4-1.0 0.5-1.2 4.0-6.0 0.2-0.8 ≤0.5 ≤0.04 ≤0.04
ZG40Cr5Mo (FED-4A) 0.35-0.45 0.4-1.0 0.5-1.2 4.0-6.0 0.2-0.8 ≤0.5 ≤0.04 ≤0.04
ZG50Cr5Mo 0.45-0.55 0.4-1.0 0.5-1.2 4.0-6.0 0.2-0.8 ≤0.5 ≤0.04 ≤0.04
ZG60Cr5Mo 0.55-0.65 0.4-1.0 0.5-1.2 4.0-6.0 0.2-0.8 ≤0.5 ≤0.04 ≤0.04
FMU-29 0.25-0.45 0.3-1.0 0.6-1.5 6.0-8.0 0.2-0.4 - ≤0.04 ≤0.04
FMU-11 0.90-1.30 0.3-1.0 0.6-1.5 11.0-13.0 0.3-0.5 - ≤0.04 ≤0.04
FMU-13 0.80-1.30 0.4-1.2 0.8-1.5 11.0-13.0 0.4-0.8 - ≤0.04 ≤0.04
FMU-14 1.60-2.00 0.4-1.2 0.8-1.5 11.0-13.0 0.6-1.0 - ≤0.04 ≤0.04
Item High Cr White Iron High Cr Alloy Steel High Mn Steel Ni-hard Cast Iron
C 2.4-3.2 1.1-2.2 0.9-1.3 2.4-3.6
Si 0.6-1.2 0.6-1.2 ≤0.8 ≤0.8
Mn 0.5-1.0 0.5-1.0 11.0-18.0 ≤2.0
Cr 12.0-30.0 11.0-30.0 1.5-2.5 1.5-10
S ≤0.04 ≤0.04 ≤0.04 ≤0.15
P ≤0.06 ≤0.06 ≤0.06 ≤0.15
Mo 0.1-3.0 0.1-3.0 ≤1.0 ≤0.1
Cu 0.1-1.0 0.1-1.0
Ni 0-0.3 0-0.3 3.3-10
Re
Equivalent
Specification
GB/T8263-1999 GB/T5680-1998 GB/T8263-1999
AS2027 Cr27 DL/T 681-1999 AS2027/Ni-Cr1-550
AS2027 CrMo 15/3 JIS G 5153-1999 AS2027/Ni-Cr2-500
AS2027 CrMo 20/2/1 ASTM A128 AS2027/Ni-Cr4-500
ASTM A532 Class  Type A 25%Cr DIN GX120Mn12 AS2027/Ni-Cr4-600
ASTM A532 Class  Type B 15%Cr-Mo AFNORZ120Mn12 AS2027/Ni-Cr4-630
BS 4844 3E ASTM A532 1-A,B,C,D
DIN1695 ASTM A532 2-A,B,C,D,E
NFA32401 ASTM A532 3-A
Material Type Martensite Matrix Austenitic Mn Steel
Hardness HRC≥56 HB≤300 HRC≥56
Impact Value AK≥4J AK≥80J
FAQ:

Q: Can you manufacture Customization products?
A: Yes, we can.
We can produce both standard and special prosucts.
Our can make them according to your drawings and samples.

Q: Do you provide free samples?
A: Yes, usually we provide free samples for testing under the condition of freight paid by customer.

Q: What is the Warranty for our products ?
A: If any quality problems on our side occurred in this period , we will take on the shipping cost and replacement.

Q: Can the products be customized as our need, such as put on our logo?
A: Surely our products can be customized as your need, Put on your logo is also available.

Q: What information do we need to provide to you in order to confirm our parts order?
A: provide us your drawings or detailed specifications for our technical staff could make the drawing.

Q:  Do you test all your goods before delivery?
 A: Yes, we have 100% test before delivery

Q: When will make delivery?
A: Delivery Time
Sample Order: 20days after receipt of the full payment.
Stock Order: 10 days after receipt of the full payment.
OEM Order: 40 days after receipt of the deposit.

Q: After-sales Service?
A: 1 year warranty for all kinds of products;
If you find any defective accessories first time, we will give you the new parts for free to replace in the next order, as an experienced manufacturer, you can rest assured of the quality and after-sales service.

Q: Transportation?
A: Transported by DHL, UPS, EMS, Fedex, Air freight, Sea freight.

Q: Do you support drop shipping?
A: Yes, your drop shipping is aviable.

Q: What kind of materials are using for the products?
A: We supply all kinds of high alloy steel castings, including manganese steel castings, high manganese steel, nickel hard castings, chromium molybdenum alloy steel, high chromium white iron castings, etc.

Q: What kinds of products do you offer?
A: We mainly produce various high alloy steel castings, such as mill liners, jaw crusher spare parts, jaw plates, cone crusher spare parts, Crusher Blow Bars, Crusher Hammers, etc.

Q: What is the maximum weight of a single piece that can be cast, and what is your daily processing capacity?
A: The weight of a single piece that can be cast at one time is 30 tons. The production capacity is 150 tons/working day.
