• INTRODUCTION
  • Product Series

Crusher Hammer Head

Product Name: Crusher Hammer Head
Process: High Aolloy Castings
Model NO: According to the drawing
Main Material: Alloy Steel & High Chromium Alloy Steel
Minimum order quantity: 5 pieces
Machining Tolerance: +/-0.01mm
Standard: GB/ AISI/ DIN/ GOST
Delivery time: 7-30 days/negotiation
Inspection: Ut, Metallographic Examination, Hardness Test etc.
Application: Used in Metallurgy, Mining, Chemical Industry, Cementand Crushing Equipment
Certification: ISO
Plant: We Have Our Own Factory
Specifications: High Dimension Accuracy, Wear Resistance
Port: Shipped from Shanghai Port to the customer’s designated unknown
Transport Package: Wooden Cases
Advantage: Rich Experience, Best Service, Professional Team.
Our Goal: Provide Top Quality Product,Satisfactory Service
Crusher Hammer Head are the most important wear parts of metal shredder crusher.
We use high manganese steel with chrome as the material to make sure the quality.

Material C Mn Si Cr P S
ZGMn13Cr2 1.0-1.3 11-14 0.3-0.6 1.7-2.4 ≤0.05 ≤0.03
ZGMn13Cr2 1.1-1.4 17-20 0.3-0.6 1.7-2.4 ≤0.05 ≤0.03
ZGMn13Cr2 1.1-1.4 20-24 0.3-0.6 1.7-2.4 ≤0.05 ≤0.03
ZGMn18Cr2 1.1-1.5 16-19 ≤0.8 1.5-2.5 ≤0.07 ≤0.04
ZGMn22Cr2 1.1-1.4 20-24 ≤0.8 1.5-2.5 ≤0.07 ≤0.04


Our Photos for Crusher Hammer Head:

  • Crusher Hammer Head
  • Crusher Hammer Head
  • Crusher Hammer Head
  • Crusher Hammer Head

Contact us:

If you have interest, please do not hesitate to contact me.
Pls send the drawing, technical requirements to us by email.
Looking forward to receiving your inquiry and reply.
Thank you.

High Manganese Steel Crusher Hammer Head Series:

They are the wear-resisting materials that are mainly used in metallurgy,mining and crushing equipment, including ordinary high manganese steel, modified high manganese steel, super-high manganese steel, multi-component alloy intensely processed high manganese steel and magnet high aluminum steel lining plates.

Medium and Low Alloy Steel Series:

These products are mainly uesd in the lining plates for power plants, coal plants, xement factories and some mining ball mills, characterized with good adaptability, non-deforming,non-breaking and twice the longevity of high manganese steel.

High Chromium Cast Iron Series:

These products are mainly used in the crushing equipment or matallurgy, mining and cement sectors, suitable for medium impact casting, With favorable cost performance and sound wear resistance,they are divided into four groups according to the service conditions:
KmBCr15, KmTBCr20, KmTBCr26 and compound type.

Compound Wear-resisting products Series:

Hardfacing wear-resistance technique and bimetal compound casting technique are adopted to make high strength wear-resisting products, with the characteristics of being easy to process and strong wear-resisting ability.
