Coal Crusher Hammers for Sale

Model NO: According to the drawing
Coating: Alloy Steel
Machining Tolerance: +/-0.01mm
Standard: GB/ AISI /DIN /GOST
Certification:ISO 9001: 2015
Application: Used in Metallurgy, Mining, Chemical Industry, Cementand Crushing Equipment
Our Advantage: Rich Experience, Best Service, Professional Team.
Inspection: Ut, Metallographic Examination, Hardness Test etc.
Plant: We Have Our Own Factory
Main Material: Alloy Steel & High Chromium Alloy Steel, High manganese steel
Specifications: High Dimension Accuracy, Wear Resistance
Our Goal: Provide Top Quality Product,Satisfactory Service
Transport Package: Wooden Cases

Specification: According to the drawing

Coal Crusher Hammer Accessory are the most important wear parts of metal shredder crusher.
We use High Manganese Steel with chrome as the material to make sure the quality.

Our Photos for Coal Crusher Hammer:

  • Crusher Hammers
  • Crusher Hammers
  • Crusher Hammers
  • Crusher Hammers
Coal Crusher Hammer Accessory are the most important wear parts of metal shredder crusher.
We use High Manganese Steel with chrome as the material to make sure the quality.

Series of High Manganese Steel Crusher Hammer:

They are the wear-resisting materials that are mainly used in metallurgy,mining and crushing equipment, including ordinary high manganese steel, modified high manganese steel, super-high manganese steel, multi-component alloy intensely processed high manganese steel and magnet high aluminum steel lining plates.

Series of High Chromium Cast Iron:

These products are mainly used in the crushing equipment or matallurgy, mining and cement sectors, suitable for medium impact casting. With favorable cost performance and sound wear resistance.
Specification:
According to drawings, heat resistance, surface treatment requirement, Various types of 2D or 3D drawings are acceptable, etc.
Cost effective:
Integrated production from mold-making to post-processing is completed in our own factory.
This can effectively reduce the manufacturing cost.
We have first rate production line, the most professional staff, and the advanced equipment and inspection method for casting.
super quality,competitive price and strict delivery time.
Standard Specification for Austenitic Manganese Steel
Reference Standard Nominal Chemical Composition (W%)
ASTM A128 C Mn Cr Mo Ni Si (Max.) S (Max.) P(Max.) Eqv. Standard GB5680
A 1.05-1.35 ≥11.0 - - - 1 0.06 0.05 GB 5680 ZGMn13-1 AS2074/H1A
B-1 0.90-1.05 11.5-14.0 - - - 1 0.06 0.05 GB 5680 ZGMn13-2
B-2 1.05-1.20 11.5-14.0 - - - 1 0.06 0.05 GB 5680 ZGMn13-2,3 AS2074/H1A
B-3 1.12-1.28 11.5-14.0 - - - 1 0.06 0.05 GB 5680 ZGMn13-2,3 AS2074/H1A
B-4 1.20-1.35 11.5-14.0 - - - 1 0.06 0.05 GB 5680 ZGMn13-2,3 AS2074/H1A
C 1.05-1.35 11.5-14.0 1.50-2.50 - - 1 0.06 0.05 GB 5680 ZGMn13-4 AS2074/H1B
D 0.70-1.30 11.5-14.0 - - 3.0-4.0 1 0.06 0.05 -
E-1 0.70-1.30 11.5-14.0 - 0.90-1.20 - 1 0.06 0.05 GB 5680 ZGMn13-5 AS2074/H1C
E-2 1.05-1.45 11.5-14.0 - 1.80-2.10 - 1 0.06 0.05 GB 5680 ZGMn13-5
F 1.05-1.35 6.0-8.0 - 0.90-1.20 - 1 0.06 0.05 -
- 1.30-1.50 ≥17.0 - - - 1 0.06 0.05 AS2074/H1D
Material C Mn Si Cr P S
ZGMn13Cr2 1.0-1.3 11-14 0.3-0.6 1.7-2.4 ≤0.05 ≤0.03
ZGMn13Cr2 1.1-1.4 17-20 0.3-0.6 1.7-2.4 ≤0.05 ≤0.03
ZGMn13Cr2 1.1-1.4 20-24 0.3-0.6 1.7-2.4 ≤0.05 ≤0.03
ZGMn18Cr2 1.1-1.5 16-19 ≤0.8 1.5-2.5 ≤0.07 ≤0.04
ZGMn22Cr2 1.1-1.4 20-24 ≤0.8 1.5-2.5 ≤0.07 ≤0.04
FAQ:

Q: Can you manufacture Customization products?
A: Yes, we can.
We can produce both standard and special prosucts.
Our can make them according to your drawings and samples.

Q: Do you provide free samples?
A: Yes, usually we provide free samples for testing under the condition of freight paid by customer.

Q: What is the Warranty for our products ?
A: If any quality problems on our side occurred in this period , we will take on the shipping cost and replacement.

Q: Can the products be customized as our need, such as put on our logo?
A: Surely our products can be customized as your need, Put on your logo is also available.

Q: What information do we need to provide to you in order to confirm our parts order?
A: provide us your drawings or detailed specifications for our technical staff could make the drawing.

Q:  Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q: When will make delivery?
A: Delivery Time
Sample Order: 20days after receipt of the full payment.
Stock Order: 10 days after receipt of the full payment.
OEM Order: 40 days after receipt of the deposit.

Q: After-sales Service?
A: 1 year warranty for all kinds of products;
If you find any defective accessories first time, we will give you the new parts for free to replace in the next order, as an experienced manufacturer, you can rest assured of the quality and after-sales service.

Q: Transportation?
A: Transported by DHL, UPS, EMS, Fedex, Air freight, Sea freight.

Q: Do you support drop shipping?
A: Yes, your drop shipping is aviable.

Q: What kind of materials are using for the products?
A: We supply all kinds of high alloy steel castings, including manganese steel castings, high manganese steel, nickel hard castings, chromium molybdenum alloy steel, high chromium white iron castings, etc.

Q: What kinds of products do you offer?
A: We mainly produce various high alloy steel castings, such as mill liners, jaw crusher spare parts, jaw plates, cone crusher spare parts, Crusher Blow Bars, Crusher Hammers, etc.

Q: What is the maximum weight of a single piece that can be cast, and what is your daily processing capacity?
A: The weight of a single piece that can be cast at one time is 30 tons. The production capacity is 150 tons/working day.
