Ball Mill Liner Manufacturers
Commonly used aliases: Mill liner, ball mill liner, partition board, grate board, ring groove liner, groove liner, step liner
Applicable equipment: Mill, vertical ball mill, lattice ball mill, overflow ball mill, tubular ball mill, rod mill, cement ball mill, etc.
Main material: High manganese steel, new composite materials, modified high manganese steel, new high manganese steel, ultra high manganese steel, super high manganese steel, metamorphic high manganese steel, multiple alloy steel, high (low) chromium cast iron Wait

Applicable materials: Ball mill is the key equipment for crushing materials after crushing. It is widely used in the production of cement, silicate products, new building materials, refractory materials, fertilizers, black and non-ferrous metal beneficiation, and glass ceramics. It is used for dry or wet grinding of various ores and other grindable materials.

Ball mill liner classification:

Ball mill liner are generally divided into five categories according to their use parts: cylinder liner, grinding head liner, partition board, grinding grate board, manhole liner and special liner. Special liner refers to components with special functions, such as retaining ring, ring, etc., although it is no longer a protective part in the traditional sense, we still call it a liner, and are classified as a special liner. class.

Ball mill liner material:

The liner material has developed from early high manganese steel, nickel hard cast iron, ordinary white cast iron, etc. to today’s several series of hundreds of varieties, mainly alloy steel, high and low chromium cast iron, austempered ductile iron and other materials.

Our Photos for Ball Mill Liner Manufacturers:

  • Ball Mill Liner
  • Ball Mill Liner
  • Ball Mill Liner

Characteristics of ball mill liner

⒈High wear resistance and impact resistance

The alloy steel liner in dual-medium quenching is scientifically and reasonably formulated with alloy elements, so that the liner has good physical and chemical properties. The hardness is above HRC45-55, the impact toughness is above 25J, and the service life is more than twice that of high manganese steel. Able to withstand huge impacts. The surface shape of the liner can be maintained for a long time during work to ensure that the output of the mill is increased by more than 5%.

⒉High strength and high toughness In the quenching process of the liner, the special dual-medium quenching agent with good thermal stability is used as the medium to make the product achieve the combination of high strength, high hardness and high toughness to meet the technical requirements of wear resistance

⒊High cost performance, strong adaptability

After the advanced dual-medium quenching process, it has the characteristics of high quenching hardness and high toughness value, so that the liner has good wear resistance. Compared with the high-manganese steel liner, the medium-alloy dual-medium quenching medium alloy steel ball mill lining The board showed an excellent cost performance. It can adapt to mine wet grinding, dry grinding, mixed grinding, etc.

Ball mill liners shape:

Its shape is no longer a simple plate shape, corner spiral, round corner square liner, groove liner, its many forms and complex shapes, there are too many to mention. So in production practice, the specific material and structure of the lining board should be selected according to the specific working conditions.

Liner of ball mill The domestic high-manganese steel is gradually replaced by medium-alloy steel liner, but with the continuous application of medium-alloy steel liner in ball mill liner, it has gradually replaced manganese steel and other liners to become the mainstream of market development. The cylinder liner not only protects the cylinder, but also has an impact on the movement of the grinding body.

In order to meet the requirements of various working conditions (crushing or fine grinding), the shape of the liner is also different. When pulverization is the main method, the liner is required to have a strong ability to push the grinding body, and at the same time, the liner should have good impact resistance. When fine grinding is the main method, the protrusion of the liner is relatively small. The pushing effect is weak, the impact is small, and the grinding effect is strong, and the liner is required to have good wear resistance.

Our Ball mill liner Capability:
EB can fabricate the Ball mill liner plates as per your material and your sizes.
EB is a professional manufacturer of high-quality ball mill liners, focusing on wear-resistant ball mill liners for 21 years. The ball mill liners produced by the company are cast from high manganese steel, high chromium      cast iron, wear-resistant alloy steel and other materials. Ball mill liners More wear-resistant and longer life than other materials!
EB provides spare parts processing business from other manufacturers all the year round, as long as you can provide processing drawings (samples), we can produce!!
Specification:
According to drawings, heat resistance, surface treatment requirement, Various types of 2D or 3D drawings are acceptable, etc.

Cost effective:
Integrated production from mold-making to post-processing is completed in our own factory.
This can effectively reduce the manufacturing cost.
We have first rate production line, the most professional staff, and the advanced equipment and inspection method for casting.
super quality,competitive price and strict delivery time.
Chemistry Standard for Grinding Mill Liners:
ISO 21988/JN/ HBW C Si Mn P S Cr Ni Mo Cu
HBW555XCr13 ≤555 1.8-3.6 ≤1 0.5-1.5 ≤0.08 ≤0.08 12-16 ≤2 ≤3 ≤1.2
HBW555XCr16 ≤555 1.8-3.6 ≤1 0.5-1.5 ≤0.08 ≤0.08 14-18 ≤2 ≤3 ≤1.2
HBW555XCr21 ≤555 1.8-3.6 ≤1 0.5-1.5 ≤0.08 ≤0.08 18-23 ≤2 ≤3 ≤1.2
HBW555XCr27 ≤555 1.8-3.6 ≤1 0.5-1.5 ≤0.08 ≤0.08 23-30 ≤2 ≤3 ≤1.2
HBW600XCr35 ≤600 3.0-5.5 ≤1 1.0-3.0 ≤0.06 ≤0.06 30-40 ≤1 ≤1.5 ≤1.2
HBW600XCr20Mo2Cu ≤600 3.0-5.5 ≤1 ≤1 ≤0.06 ≤0.06 18-21 ≤1 1.4-2.0 0.8-1.2
Standard Specification for Cr-Mo Alloy Steel
Reference Standard Nominal Chemical Composition (W%)
C Si Mn Cr Mo Ni P S
AS 2017/L2A 0.45-0.55 ≤0.75 0.50-1.00 0.80-1.20 - - ≤0.04 ≤0.04
AS 2017/L2B 0.55-0.65 ≤0.75 0.50-1.00 0.80-1.50 0.2-0.4 - ≤0.04 ≤0.04
AS 2017/L2C 0.70-0.90 ≤0.75 0.50-1.20 1.30-2.40 0.2-0.4 - ≤0.04 ≤0.04
ZG42Cr2Si2MnMo 0.38-0.48 1.5-1.8 0.8-1.2 1.8-2.2 0.2-0.6 - ≤0.04 ≤0.04
ZG45Cr2Mo 0.40-0.48 0.8-1.2 0.4-1.0 1.7-2.0 0.8-1.2 ≤0.5 ≤0.04 ≤0.04
ZG30Cr5Mo 0.25-0.35 0.4-1.0 0.5-1.2 4.0-6.0 0.2-0.8 ≤0.5 ≤0.04 ≤0.04
ZG40Cr5Mo (FED-4A) 0.35-0.45 0.4-1.0 0.5-1.2 4.0-6.0 0.2-0.8 ≤0.5 ≤0.04 ≤0.04
ZG50Cr5Mo 0.45-0.55 0.4-1.0 0.5-1.2 4.0-6.0 0.2-0.8 ≤0.5 ≤0.04 ≤0.04
ZG60Cr5Mo 0.55-0.65 0.4-1.0 0.5-1.2 4.0-6.0 0.2-0.8 ≤0.5 ≤0.04 ≤0.04
FMU-29 0.25-0.45 0.3-1.0 0.6-1.5 6.0-8.0 0.2-0.4 - ≤0.04 ≤0.04
FMU-11 0.90-1.30 0.3-1.0 0.6-1.5 11.0-13.0 0.3-0.5 - ≤0.04 ≤0.04
FMU-13 0.80-1.30 0.4-1.2 0.8-1.5 11.0-13.0 0.4-0.8 - ≤0.04 ≤0.04
FMU-14 1.60-2.00 0.4-1.2 0.8-1.5 11.0-13.0 0.6-1.0 - ≤0.04 ≤0.04

Ball mill liner Common technical parameters:

Model

Rotating speed of cylinder(r/min)

Ball load(t)

Feed size(mm)

Discharge size(mm)

output(t/h)

Motor Power(kw)

Machine weight(T)

900×1800

38

1.5

≤20

0.075-0.89

0.65-2

18.5

3.6

900×3000

38

2.7

≤20

0.075-0.89

1.1-3.5

22

4.6

1200×2400

32

3.8

≤25

0.075-0.6

1.5-4.8

45

12.5

1200×3000

32

5

≤25

0.074-0.4

1.6-5

45

12.8

1200×4500

32

7

≤25

0.074-0.4

1.6.5.8

55

13.8

1500×3000

27

8

≤25

0.074-0.4

2-5

90

17

1500×4500

27

14

≤25

0.074-0.4

3-6

110

21

1500×5700

27

15

≤25

0.074-0.4

3.5-8

132

24.7

1830×3000

24

11

≤25

0.074-0.4

4-10

180

28

1830×6400

24

23

≤25

0.074-0.4

6.5-15

210

34

1830×7000

24

25

≤25

0.074-0.4

7.5-17

245

36

2200×5500

21

30

≤25

0.074-0.4

10.22

370

48.5

2200×6500

21

31

≤25

0.074-0.4

14-26

380

52.8

2200×7500

21

33

≤25

0.074-0.4

16-29

380

56

2400×7000

21

34.5

≤25

0.074-0.4

18-32

400

62.8

2400×8000

20.4

36

≤25

0.06-0.08

18-36

410

81.2

2700×3600

18

37

≤25

<0.08

50

410

77.5

FAQ:

Q: Can you manufacture Customization products?
A: Yes, we can.
We can produce both standard and special prosucts.
Our can make them according to your drawings and samples.

Q: Do you provide free samples?
A: Yes, usually we provide free samples for testing under the condition of freight paid by customer.

Q: What is the Warranty for our products ?
A: If any quality problems on our side occurred in this period , we will take on the shipping cost and replacement.

Q: Can the products be customized as our need, such as put on our logo?
A: Surely our products can be customized as your need, Put on your logo is also available.

Q: What information do we need to provide to you in order to confirm our parts order?
A: provide us your drawings or detailed specifications for our technical staff could make the drawing.

Q:  Do you test all your goods before delivery?
 A: Yes, we have 100% test before delivery

Q: When will make delivery?
A: Delivery Time
Sample Order: 20days after receipt of the full payment.
Stock Order: 10 days after receipt of the full payment.
OEM Order: 40 days after receipt of the deposit.

Q: After-sales Service?
A: 1 year warranty for all kinds of products;
If you find any defective accessories first time, we will give you the new parts for free to replace in the next order, as an experienced manufacturer, you can rest assured of the quality and after-sales service.

Q: Transportation?
A: Transported by DHL, UPS, EMS, Fedex, Air freight, Sea freight.

Q: Do you support drop shipping?
A: Yes, your drop shipping is aviable.

Q: What kind of materials are using for the products?
A: We supply all kinds of high alloy steel castings, including manganese steel castings, high manganese steel, nickel hard castings, chromium molybdenum alloy steel, high chromium white iron castings, etc.

Q: What kinds of products do you offer?
A: We mainly produce various high alloy steel castings, such as mill liners, jaw crusher spare parts, jaw plates, cone crusher spare parts, Crusher Blow Bars, Crusher Hammers, etc.

Q: What is the maximum weight of a single piece that can be cast, and what is your daily processing capacity?
A: The weight of a single piece that can be cast at one time is 30 tons. The production capacity is 150 tons/working day.
